3D PVD Coating

/

HCP+

A uniquely developed coating which is PVD Superior Hard-Chromium Coating which has a very homogeneous structure along with low density of pores with a good Non-Stick property.

TIN

Is a Golden coating which is Very Hard and due to which it works great against Wear resistance which is also used for both Punch & Die to protect it from Wear & Corrosion.

  1. CRN+

    Is a Silver Black coating which is Hard and is a Double layer of Chromium Nitride coating on the Punch surface which results in a almost pore free surface which helps in Compression of Abrasive Tablets making it more durable and sustainable in such environment.

  2. CRX+

    Is a Dark Grey coating which along with 2 layers of coating has a 3rd Thick & Dense layer of surface coat which helps further in dealing with Abrasion, Sticking, Wear & Galling also adding up the durability of the Punch with increased service life

  3. SPN

    Is a Silver Grey coating which is the Best performer against Heavy Sticking & Picking issues due to its Nano structure the surface on which it is applied gets a pore free surface finish and provides a very smooth surface area which is unmatched by any other surface coating.

  4. MLY

    A Mild Silver coating which is a combination coating which is a two layer coating which has a additional surface with anti stick properties which further reduces the effect of formulation sticking on the Punch Face

    1. CRN

      It is a Extremely Hard and inert coating with upto 2X harder then Hard Chrome which performs well in Corrosive environment and in sliding Wear applications. It also has Low Residual Stress and is Low Coefficient to friction.

  2. CRX

    Is a Greyish coating which is specially developed to also work with Abrasion and Sticking at the same time which is also a combination coating which has triple layer protection to give the best results for Sticking & Wear related issues

  3. SPN+

    Is a Silver Grey coating which is dense thick layer of an already super fine coating which helps in Heavy Sticky Tableting conditions due to its Nano structure it gives the Best surface finish which is uncomparable with any other surface coating

  4. DLC

    It‘s called Diamond Like Carbon coating which is Black and is a Nano Composite coating which has a unique property of natural diamond low friction, high hardness and high corrosion resistance which is perfectly suited for most extreme tableting conditions.
